8th Grade Angles and Parallel Lines Quiz – Ten Questions Explained

    Key takeaway: This grade 8 angles parallel lines quiz asks ten multiple-choice questions on triangle angles, exterior angles, transversals, and similar triangles. Choose an answer, and then read the note below it. Each explanation names the rule that gives the measure, and it shows why the tempting wrong choices fail.

    Several wrong options mix up supplementary and equal angles. Others forget that an outside angle is the total of the two far inside angles.

    Ten multiple-choice questions check triangle angle sums, exterior angles, angles formed by a transversal and the AA criterion. Each question has exactly one correct answer. Read the explanation to learn the typical mistake.

    Grade 8Common Core: 8.G.A.5
    🎯 Angles, Parallel Lines and Triangles – Grade 8 math quiz
    Score: 0 / 10
    Answered: 0 / 10

    Question 1

    Two angles of a triangle measure \(38^{\circ}\) and \(74^{\circ}\). What is the third angle?
    A \(112^{\circ}\)
    B \(142^{\circ}\)
    C \(78^{\circ}\)
    D \(68^{\circ}\)

    Question 2

    The remote interior angles of a triangle measure \(47^{\circ}\) and \(62^{\circ}\). What is the exterior angle?
    A \(71^{\circ}\)
    B \(109^{\circ}\)
    C \(133^{\circ}\)
    D \(118^{\circ}\)

    Question 3

    Lines \(l\) and \(m\) are parallel. What is the measure of the angle marked \(?\)

    lmt125°?
    Lines \(l\) and \(m\) are parallel.
    A \(55^{\circ}\)
    B \(65^{\circ}\)
    C \(235^{\circ}\)
    D \(125^{\circ}\)

    Question 4

    Two parallel lines are cut by a transversal. Same-side interior angles measure \((2x+10)^{\circ}\) and \((3x+20)^{\circ}\). What is \(x\)?
    A \(x=30\)
    B \(x=36\)
    C \(x=20\)
    D \(x=60\)

    Question 5

    Two parallel lines are cut by a transversal. Which pair of angles is always equal?
    A Corresponding angles
    B Same-side interior angles
    C Angles that form a linear pair
    D Angles that are next to each other along the transversal

    Question 6

    What is the measure of the exterior angle \(x\)?

    ABC50°60°x
    Triangle \(ABC\).
    A \(70^{\circ}\)
    B \(130^{\circ}\)
    C \(120^{\circ}\)
    D \(110^{\circ}\)

    Question 7

    Which pair of triangles must be similar?
    A One has angles \(40^{\circ}\) and \(80^{\circ}\); the other has angles \(40^{\circ}\) and \(70^{\circ}\)
    B One has angles \(50^{\circ}\) and \(60^{\circ}\); the other has angles \(70^{\circ}\) and \(60^{\circ}\)
    C One has angles \(50^{\circ}\) and \(60^{\circ}\); the other has angles \(60^{\circ}\) and \(80^{\circ}\)
    D One has angles \(30^{\circ}\) and \(90^{\circ}\); the other has angles \(60^{\circ}\) and \(60^{\circ}\)

    Question 8

    The triangles are similar. \(AB=6\), \(BC=8\) and \(DE=9\). What is \(EF\)?

    ABC60°70°DEF60°70°
    Triangles \(ABC\) and \(DEF\).
    A \(11\)
    B \(\frac{16}{3}\)
    C \(12\)
    D \(18\)

    Question 9

    The angles of a triangle are in the ratio \(2:3:4\). What is the largest angle?
    A \(60^{\circ}\)
    B \(90^{\circ}\)
    C \(80^{\circ}\)
    D \(72^{\circ}\)

    Question 10

    Two parallel lines are cut by a transversal, and one of the eight angles measures \(70^{\circ}\). How many of the eight angles measure \(70^{\circ}\)?
    A 4
    B 2
    C 6
    D 8

    🎉 Quiz complete!

    0 / 10

    Remember:

    • Standard 8.G.A.5: angle sum, exterior angles, parallel lines with a transversal, and the AA criterion.
    • Triangle angle sum: \(180^{\circ}\).
    • Exterior angle = sum of the two remote interior angles.
    • Parallel lines: corresponding, alternate interior and alternate exterior angles are equal; same-side interior angles sum to \(180^{\circ}\).
    • AA criterion: two equal pairs of angles make triangles similar.

    How do you answer the triangle questions?

    The first item gives angles of 38 and 74, so the third is 68 degrees. The second gives remote interior angles of 47 and 62, so the exterior angle is 109. A third item uses the ratio 2 to 3 to 4, and the angles must add to 180, so each part is 20 and the largest angle is 80 degrees.

    What does a grade 8 angles parallel lines quiz ask about transversals?

    One item asks which pair is always equal, and corresponding angles are. Another sets same-side interior angles as 2x plus 10 and 3x plus 20, and since they add to 180, x is 30. A third asks how many of the eight angles equal 70 when one does, and the answer is four. A marked angle in a figure measures 125 degrees.

    How do similar triangles appear?

    Only one pair of triangles must be similar, namely the pair with angles 50 and 60 in one and the matching angles in the other. For triangles with AB equal to 6, BC equal to 8, and DE equal to 9, the scale factor is 1.5, so EF is 12. Check the correspondence before you multiply.

    Which mistake is most common?

    Students often call same-side interior angles equal. They are supplementary, so they total 180. A quick sketch avoids this slip.

    After the angles quiz

    Redo each miss, and name the relationship before you calculate. Next, test your answer by adding angles on a line or in a triangle. Then print the worksheet and choose figures that resemble your errors, so the practice targets your weak spots.

    Next step after this grade 8 angles parallel lines quiz: Angles, Parallel Lines and Triangles lesson

    Printable PDF · Quiz

    Grade 8 Angles, Parallel Lines and Triangles quiz

    • 📄 US Letter
    • 💾 92 KB
    • 🖨️ Black and white friendly
    Download the PDF
