Geometry Circles, Angles and Arcs Quiz with Answers – 10 Questions

    Key takeaway: This geometry circles angles arcs quiz presents ten multiple-choice questions about circle theorems. Plan on about 15 minutes. You will use an inscribed angle, a diameter, a tangent, a chord and a cyclic quadrilateral. Select one answer and read the reasoning that follows.

    This 10-question quiz checks the core circle facts: similar circles, central and inscribed angles, semicircles, tangents, chords and inscribed quadrilaterals. Choose the one best answer for each question and read the explanation afterward.

    GeometryCommon Core: G-C.A.1 · G-C.A.2
    🎯 Circles: Chords, Arcs and Inscribed Angles – Geometry math quiz
    Score: 0 / 10
    Answered: 0 / 10

    Question 1

    Which statement about circles is true?
    A Two circles are similar only if their radii are equal
    B Any two circles are similar
    C Two circles are similar only if they share a center
    D Circles with different radii are never similar

    Question 2

    Arc \(AB\) measures \(100^{\circ}\). What is \(m\angle ACB\)?
    ABCOarc 100°
    Arc AB measures 100°.
    A \(100^{\circ}\)
    B \(50^{\circ}\)
    C \(200^{\circ}\)
    D \(25^{\circ}\)

    Question 3

    An inscribed angle intercepts an arc of \(98^{\circ}\). What is the measure of the inscribed angle?
    A \(98^{\circ}\)
    B \(196^{\circ}\)
    C \(24.5^{\circ}\)
    D \(49^{\circ}\)

    Question 4

    Segment \(AB\) is a diameter and \(m\angle A=25^{\circ}\). What is \(m\angle B\)?
    ABC25°
    Segment AB is a diameter.
    A \(25^{\circ}\)
    B \(90^{\circ}\)
    C \(155^{\circ}\)
    D \(65^{\circ}\)

    Question 5

    A tangent segment \(AP\) is 12 long and the radius \(OA\) is 9. What is \(OP\)?
    A \(15\)
    B \(21\)
    C \(\sqrt{63}\)
    D \(225\)

    Question 6

    Tangent segments \(PA\) and \(PB\) are drawn and minor arc \(AB\) measures \(100^{\circ}\). What is \(m\angle P\)?
    ABP100°O
    Minor arc AB measures 100°.
    A \(80^{\circ}\)
    B \(100^{\circ}\)
    C \(50^{\circ}\)
    D \(40^{\circ}\)

    Question 7

    Quadrilateral \(ABCD\) is inscribed in a circle and \(m\angle A=78^{\circ}\). What is \(m\angle C\)?
    A \(78^{\circ}\)
    B \(90^{\circ}\)
    C \(102^{\circ}\)
    D \(282^{\circ}\)

    Question 8

    A chord is 16 units long in a circle of radius 10. How far is the chord from the center?
    OABM1016d = ?
    A chord and the perpendicular from the center.
    A \(8\)
    B \(2\)
    C \(6\)
    D \(\sqrt{164}\)

    Question 9

    Two chords of the same circle have equal length. Which must be true?
    A Both chords pass through the center
    B The chords are parallel
    C The chords intersect at right angles
    D Their intercepted minor arcs have equal measure

    Question 10

    A central angle and an inscribed angle intercept the same arc. The central angle measures \(148^{\circ}\). What does the inscribed angle measure?
    A \(148^{\circ}\)
    B \(37^{\circ}\)
    C \(74^{\circ}\)
    D \(296^{\circ}\)

    🎉 Quiz complete!

    0 / 10

    Remember:

    • All circles are similar: a translation and a dilation with factor \(\frac{r_2}{r_1}\) map one onto another.
    • A central angle equals its arc; an inscribed angle equals half its arc.
    • An angle inscribed in a semicircle measures \(90^{\circ}\).
    • A radius is perpendicular to a tangent, and a circumscribed angle is \(180^{\circ}\) minus its minor arc.
    • Opposite angles of an inscribed quadrilateral are supplementary.

    What does the geometry circles angles arcs quiz cover?

    Question 1 asks which statement is true, and the answer is that any two circles are similar. Question 2 gives an arc of 100 degrees, so the inscribed angle is 50 degrees. Then question 4 uses a diameter with a 25 degree angle, so the other acute angle is 65 degrees.

    Which items need extra care?

    Question 5 has a tangent of 12 and radius 9, so \(OP=15\). Next, question 6 turns a 100 degree arc into an outside angle of 80 degrees. Finally, question 8 places a 16-unit chord in a circle of radius 10, so the distance is 6, not 8.

    How do you handle the last questions?

    Question 9 says two equal chords cut equal minor arcs. Question 10 starts from a central angle of 148 degrees, so the inscribed angle is 74 degrees.

    What if you miss some answers?

    List which theorem each miss needed. Then revisit worksheet problems 4, 10 and 14. Afterward, take the quiz once more.

    Next step after this geometry circles angles arcs quiz: Circles: Chords, Arcs and Inscribed Angles lesson

    Printable PDF · Quiz
