AP Calculus AB Applications of Integration Test Answer Key – Rubric PDF

    Key takeaway: This AP calculus applications test answer key presents each worked integral together with a mark scheme covering all 20 points. Graders award one point for a correct setup, one for the evaluation and, where a context is given, one for units. Any equivalent exact form earns full marks. This key tracks the AB course and notes the limits of integration that students most often reverse.

    Full solutions and a scoring guide for the applications of integration test. Points follow AP-style rubrics: one for the setup, one for the limits or integrand, and one for the final value, so partial credit is explained for every question.

    AP Calculus ABCommon Core: AP Calculus AB Unit 8

    AP Calculus Applications Test Answer Key: questions 1–5

    1. Average value (2 points)

    1. \(\int_{0}^{2}x^{3}\,dx=4\), so \(f_{\text{avg}}=\frac{4}{2}=2\).
    2. \(c^{3}=2\), so \(c=2^{1/3}\approx 1.260\).

    (a) 2; (b) \(c\approx 1.260\)

    Scoring: 1 point for the average value 2; 1 point for \(c\approx 1.260\).

    2. Particle motion (3 points)

    12345−12468tv20/34/34/3
    Areas of the three regions.

    \(v=(t-2)(t-4)\). Antiderivative: \(\frac{t^{3}}{3}-3t^{2}+8t\).

    1. \(\int_{0}^{5}v\,dt=\frac{125}{3}-75+40=\frac{20}{3}\), so \(s(5)=1+\frac{20}{3}=\frac{23}{3}\).
    2. \(\int_{0}^{2}v\,dt=\frac{20}{3}\), \(\int_{2}^{4}v\,dt=-\frac{4}{3}\), \(\int_{4}^{5}v\,dt=\frac{4}{3}\). Distance \(=\frac{20}{3}+\frac{4}{3}+\frac{4}{3}=\frac{28}{3}\).

    (a) \(\frac{23}{3}\); (b) \(\frac{28}{3}\)

    Scoring: (a) 1 point. (b) 1 point for splitting at \(t=2\) and \(t=4\); 1 point for \(\frac{28}{3}\).

    3. Area between curves (2 points)

    Intersections: \(6x-x^{2}=x^{2}\) gives \(2x(3-x)=0\), so \(x=0\) and \(x=3\). The parabola \(6x-x^{2}\) is on top.

    \(A=\int_{0}^{3}(6x-2x^{2})\,dx=[3x^{2}-\frac{2x^{3}}{3}]_{0}^{3}=27-18=9\).

    9

    Scoring: 1 point for the correct limits and integrand; 1 point for the value 9.

    4. Area using y (2 points)

    \(y^{2}=6-y\) gives \(y^{2}+y-6=0\), so \(y=-3\) or \(y=2\). The line \(x=6-y\) is the right curve.

    \(A=\int_{-3}^{2}(6-y-y^{2})\,dy=[6y-\frac{y^{2}}{2}-\frac{y^{3}}{3}]_{-3}^{2}=\frac{22}{3}-(-\frac{27}{2})=\frac{125}{6}\).

    \(\frac{125}{6}\)

    Scoring: 1 point for the limits and integrand; 1 point for \(\frac{125}{6}\).

    5. Semicircle cross sections (3 points)

    −2−1121234xyy = 4y = x²
    The base of the solid.

    The diameter at \(x\) is \(4-x^{2}\), for \(-2\le x\le 2\). The area is \(\frac{\pi}{2}(\frac{4-x^{2}}{2})^{2}=\frac{\pi}{8}(4-x^{2})^{2}\).

    \(V=\frac{\pi}{8}\int_{-2}^{2}(4-x^{2})^{2}\,dx=\frac{\pi}{8}\cdot\frac{512}{15}=\frac{64\pi}{15}\approx 13.404\).

    \(\frac{64\pi}{15}\)

    Scoring: 1 point for the semicircle area \(\frac{\pi}{8}(4-x^{2})^{2}\); 1 point for the integral setup with limits; 1 point for the value.

    AP Calculus Applications Test Answer Key: questions 6–8

    6. Washer method (3 points)

    123412xyy = √xy = x/2R = √x (outer), r = x/2 (inner)
    The region to revolve about the \(x\)-axis.

    Intersections: \(\sqrt{x}=\frac{x}{2}\) at \(x=0\) and \(x=4\). Outer radius \(R=\sqrt{x}\), inner radius \(r=\frac{x}{2}\).

    \(V=\pi\int_{0}^{4}(x-\frac{x^{2}}{4})dx=\pi(8-\frac{16}{3})=\frac{8\pi}{3}\).

    \(\frac{8\pi}{3}\)

    Scoring: 1 point for the limits; 1 point for \(\pi(R^{2}-r^{2})\) with correct radii; 1 point for the value.

    7. Rates of change (3 points)

    \(A^{\prime}(t)=2t-6\).

    1. \(A(6)=50+\int_{0}^{6}(2t-6)\,dt=50+(36-36)=50\).
    2. \(A^{\prime}(t)=0\) at \(t=3\); \(A^{\prime}<0\) before and \(A^{\prime}>0\) after, so \(A\) is least at \(t=3\) (the endpoints are \(A(0)=50\) and \(A(8)=66\)).
    3. \(A(3)=50+(9-18)=41\).

    (a) 50; (b) \(t=3\); (c) 41 hundred people

    Scoring: 1 point for each part.

    8. Area with three intersections (2 points)

    \(x^{3}-9x=x(x-3)(x+3)\), so the graph meets the axis at \(x=-3,0,3\). On \([-3,0]\) it is above the axis; on \([0,3]\) below.

    \(\int_{-3}^{0}(x^{3}-9x)\,dx=0-(\frac{81}{4}-\frac{81}{2})=\frac{81}{4}\). \(\int_{0}^{3}(x^{3}-9x)\,dx=\frac{81}{4}-\frac{81}{2}=-\frac{81}{4}\). Area \(=\frac{81}{4}+\frac{81}{4}=\frac{81}{2}\).

    \(\frac{81}{2}\)

    Scoring: 1 point for the three intersections and the split; 1 point for \(\frac{81}{2}\).

    Scoring summary

    Total

    20 points: add the points of every question of this ap calculus applications test answer key.

    Which values open the answer key?

    Question 1 gives an average value of 2 and \(c=\sqrt[3]{2}\). Then the area in question 3 is 9, since \(\int_0^3(6x-2x^2)\,dx=27-18\). Finally, the region in question 4 measures \(\frac{125}{6}\).

    How do you score the area with three intersections?

    Question 8 needs two integrals, one on \([-3,0]\) and one on \([0,3]\). Each region has area \(\frac{81}{4}\), so the total is \(\frac{81}{2}\). A student who integrates once from \(-3\) to 3 gets zero, and that response earns only the setup point.

    What does the AP calculus applications test key say about the particle?

    The velocity \((t-2)(t-4)\) is positive before 2, negative between 2 and 4, and positive again after 4. Therefore total distance is the sum of three absolute integrals. Award credit for the split even if one evaluation slips.

    Which partial credit rules apply to volumes?

    Give the setup point for a correct integrand such as \(\pi(R^2-r^2)\). However, withhold it when the outer and inner radii are swapped, because the volume would be negative.

    How can teachers turn the rubric into reteaching?

    Count which rubric line was lost most often. When limits are the issue, project one region and mark its intersections together. After that, assign a short follow-up with two area problems and one solid, and compare class results.
