Algebra 2 Trig Graphs Worksheet with Answers – Sine and Cosine, PDF

    Key takeaway: This algebra 2 trig graphs worksheet provides 22 printable problems on key values, amplitude, period, midline, phase shift and real-world models. Standards F-TF.B.5 along with F-IF.C.7e apply. Problems 1 to 6 build vocabulary, problems 7 to 14 read and sketch graphs, and problems 15 to 22 write equations and answer questions about tides, a Ferris wheel and a spring. Plan about 55 minutes.

    These 22 problems build the skills in standards F-TF.B.5 and F-IF.C.7e. You will evaluate sine and cosine at key angles, find amplitude, period, midline and phase shift, read equations from graphs, and write sinusoidal models.

    The problems move from key values to full equations. The last six are word problems about tides, a Ferris wheel, daylight hours, a buoy, temperature and a spring. Use radian mode on your calculator.

    Algebra 2Common Core: F-TF.B.5 · F-IF.C.7e

    Algebra 2 Trig Graphs Worksheet: problems 1–5

    1. Sine at key angles

    Evaluate each expression.

    1. \(\sin 0\)
    2. \(\sin\frac{\pi}{2}\)
    3. \(\sin \pi\)
    4. \(\sin\frac{3\pi}{2}\)
    5. \(\sin 2\pi\)

    2. Cosine at key angles

    Evaluate each expression.

    1. \(\cos 0\)
    2. \(\cos\frac{\pi}{2}\)
    3. \(\cos \pi\)
    4. \(\cos\frac{3\pi}{2}\)
    5. \(\cos 2\pi\)

    3. Find the amplitude

    State the amplitude of each function.

    1. \(y=4\sin x\)
    2. \(y=-3\cos x\)
    3. \(y=\frac{1}{2}\sin x\)
    4. \(y=2.5\cos x\)

    4. Find the period

    Find the period of each function.

    1. \(y=\sin 2x\)
    2. \(y=\cos 4x\)
    3. \(y=\sin\frac{x}{2}\)
    4. \(y=\cos(\pi x)\)
    5. \(y=\sin 3x\)

    5. Midline and range

    Find the midline and the range of each function.

    1. \(y=\sin x+3\)
    2. \(y=2\cos x-1\)
    3. \(y=-4\sin x+2\)

    Algebra 2 Trig Graphs Worksheet: problems 6–10

    6. Read the phase shift

    Describe the horizontal shift of each graph compared with its parent function.

    1. \(y=\sin(x-\frac{\pi}{4})\)
    2. \(y=\cos(x+\frac{\pi}{3})\)
    3. \(y=\sin(2(x-\frac{\pi}{6}))\)
    4. \(y=\cos(x-\frac{3\pi}{2})\)

    7. Equation from a cosine graph

    The graph shows \(y=A\cos x\). Find \(A\) and write the equation.

    0π/2π3π/22π-4-3-2-101234xy
    Cosine wave for Problem 7.

    8. Midline from a graph

    The graph shows a sine wave. Find its maximum, minimum, midline and amplitude, then write its equation in the form \(y=A\sin x+D\).

    0π/2π3π/22π-2-101234xy
    Sine wave for Problem 8.

    9. Period from a graph

    Find the period of the graph and the value of \(B\), then write an equation of the form \(y=A\cos(Bx)\).

    0π/2π3π/22π-3-2-10123xy
    Cosine wave for Problem 9.

    10. Evaluate a sinusoid

    Let \(f(x)=2\sin x+1\). Find each value.

    1. \(f(\frac{\pi}{6})\)
    2. \(f(\frac{\pi}{2})\)
    3. \(f(\frac{7\pi}{6})\)
    4. \(f(\frac{3\pi}{2})\)

    Algebra 2 Trig Graphs Worksheet: problems 11–15

    11. Maximum and minimum values

    Find the maximum and minimum value of each function.

    1. \(y=5\sin x+2\)
    2. \(y=-2\cos x-1\)

    12. Three features at once

    Find the amplitude, period and midline of \(y=3\cos(4x)-2\).

    13. Plot key points

    Complete the table of values for \(y=3\sin x\), plot the five points on the grid, and sketch one full cycle.

    \(x\) \(0\) \(\frac{\pi}{2}\) \(\pi\) \(\frac{3\pi}{2}\) \(2\pi\)
    \(y\)
    0π/2π3π/22π-3-2-10123xy
    Grid for Problem 13.

    14. All four features

    Find the amplitude, period, phase shift and midline of \(y=-3\sin(2(x+\frac{\pi}{4}))+1\). Then state its maximum and minimum values.

    15. Write a sine equation

    Write an equation of the form \(y=A\sin(Bx)+D\) for a sine wave with amplitude \(4\), period \(\pi\) and midline \(y=1\).

    Algebra 2 Trig Graphs Worksheet: problems 16–20

    16. Write a cosine equation

    A cosine wave has maximum value \(8\), minimum value \(2\) and period \(8\). Write an equation of the form \(y=A\cos(Bx)+D\) with \(A > 0\).

    17. Tide model

    The depth of water at a harbor pier is \(D(t)=5+3\cos(\frac{\pi t}{6})\) feet, where \(t\) is the number of hours after midnight.

    1. Find the amplitude, period and midline.
    2. Find the highest and lowest depths.
    3. Find \(D(2)\) and \(D(4)\).
    036912151821240123456789midline y = 5hours after midnight (t)depth (ft)
    Tide depth over one day for Problem 17.

    18. Ferris wheel

    Maya rides a Ferris wheel whose height above the ground is \(h(t)=28-25\cos(\frac{\pi t}{20})\) feet after \(t\) seconds.

    1. How many seconds does one full turn take?
    2. Find the lowest and highest heights.
    3. Find Maya’s height at \(t=10\) and at \(t=5\). Round to the nearest tenth.
    0204060800102030405060midline y = 28time t (seconds)height (ft)
    Wheel height for Problem 18.

    19. Daylight hours

    In Seattle, the number of daylight hours on day \(t\) of the year is modeled by \(D(t)=12+2.5\sin(\frac{2\pi(t-80)}{365})\).

    1. Find the amplitude, period, midline and phase shift.
    2. Find the longest and shortest number of daylight hours.
    3. Find \(D(125)\) to the nearest tenth of an hour.

    20. Bobbing buoy

    A buoy bobs between \(14\text{ ft}\) and \(8\text{ ft}\) above the ocean floor. It reaches its highest point at \(t=0\) seconds and completes one cycle every \(4\) seconds.

    1. Write a model \(h(t)=A\cos(Bt)+D\) with \(A > 0\).
    2. Find the height at \(t=1.5\) seconds. Round to the nearest tenth.
    3. Find the first time the buoy is at the midline height.

    Algebra 2 Trig Graphs Worksheet: problems 21–22

    21. Daily temperature

    Jamal models the temperature in his town as \(T(t)=62+14\sin(\frac{\pi(t-9)}{12})\) degrees Fahrenheit, where \(t\) is the number of hours after midnight.

    1. Find the highest and lowest temperatures, and the times they occur in the first 24 hours.
    2. Find the temperature at noon, to the nearest tenth of a degree.
    3. Find the times in the first 24 hours when the temperature equals \(62^{\circ}\text{F}\).

    22. Spring and weight

    A weight on a spring hangs \(h(t)=30+6\cos(\frac{2\pi t}{3})\) inches above a table after \(t\) seconds.

    1. Find the amplitude and the period.
    2. Find \(h(1)\).
    3. Find all times in the first \(3\) seconds when the weight is \(33\) inches above the table.

    Graphs of Trigonometric Functions: Algebra 2 worksheet answer key

    How do the first six problems prepare you?

    Problems 1 and 2 evaluate sine and cosine at 0, \(\frac{\pi}{2}\), \(\pi\), \(\frac{3\pi}{2}\) and \(2\pi\), which gives the pattern 0, 1, 0, \(-1\), 0 for sine. Then problem 3 asks for amplitudes such as 4 and \(\frac{1}{2}\). Problem 4 asks for periods, so \(y=\sin 2x\) has period \(\pi\). For \(y=\cos(\pi x)\), the period is 2.

    What do students miss in graph problems?

    Midline and amplitude are often mixed up. The maximum minus the minimum, divided by two, gives the amplitude. In problem 14, \(y=-3\sin(2(x+\frac{\pi}{4}))+1\) has amplitude 3, period \(\pi\), a shift left \(\frac{\pi}{4}\) and midline \(y=1\). The negative sign flips the curve, but it does not change the amplitude.

    How do the models read?

    The tide in problem 17 swings between 2 and 8 feet with a 12-hour period. The Ferris wheel \(h(t)=28-25\cos(\frac{\pi t}{20})\) bottoms at 3 feet, tops out at 53 and repeats every 40 minutes. The spring in problem 22 bobs between 24 and 36 inches every 3 seconds. In each case, units belong in the final sentence.

    How can you check your work?

    Plug the time of one maximum into each model and confirm that you get the maximum value. Also test a time at the start of a cycle. If both match, your equation is probably right. Last, read the solutions, then take the quick quiz.

    Next step after this algebra 2 trig graphs worksheet: Graphs of Trigonometric Functions worksheet answer key

    Printable PDF · Worksheet

    Algebra 2 Graphs of Trigonometric Functions worksheet

    • 📄 US Letter
    • 💾 124 KB
    • 🖨️ Black and white friendly
    Download the PDF

    See every chapter on the Algebra 2 math page.
