4th Grade Angles Lesson (Grade 4) – Measure, Draw, and Add Angles

    Key takeaway: This grade 4 angles lesson explains an angle as the turn between two rays that share an endpoint. A full turn is 360 degrees, so the smallest unit, one degree, cuts the circle into 360 slices. First, you link quarter, half, and full turns to 90, 180, and 360 degrees. Then you read and draw angles with a protractor. Finally, you add the measures of parts to find the whole angle or an unknown part.

    An angle measures how far a ray turns around its endpoint. A full turn is 360 degrees, so a one-degree angle is \(\frac{1}{360}\) of a circle. Use a protractor to measure angles in degrees. Angle measures add: if an angle is split into parts, the whole equals the sum, as in \(35^{\circ} + 40^{\circ} = 75^{\circ}\).

    Grade 4Common Core: 4.MD.C.5 · 4.MD.C.6 · 4.MD.C.7

    Grade 4 Angles Lesson: key facts

    • A one-degree angle turns through 1/360 of a circle.
    • A quarter turn is 90 degrees, a half turn is 180 degrees, and a full turn is 360 degrees.
    • To use a protractor, put its center on the vertex and one ray on the 0 mark.
    • The measure of a whole angle is the sum of the measures of its non-overlapping parts.
    • Use a letter for an unknown angle and solve an addition or subtraction equation.

    What is an angle and how is it measured?

    An angle is made by two rays that share an endpoint called the vertex. Think of an angle as a turn: one ray swings around the vertex to a new position, and the size of the turn is the angle measure. A full turn brings the ray back to where it started. A circle is cut into 360 equal turns, called degrees.

    1/4 turn = 90°1/2 turn = 180°3/4 turn = 270°full turn = 360°
    A full turn is 360 degrees. A quarter turn is one fourth of that.
    One-degree angle

    A one-degree angle turns through \(\frac{1}{360}\) of a circle. An angle that opens through \(n\) one-degree angles has a measure of \(n\) degrees. A quarter turn is \(90^{\circ}\), a half turn is \(180^{\circ}\), and a full turn is \(360^{\circ}\).

    What does a one-degree angle look like?

    Imagine a circular pizza cut into 360 thin slivers. Each sliver is a one-degree angle. Place 30 slivers side by side and the angle is \(30^{\circ}\).

    One slice of the circle is a one-degree angle. Thirty slices side by side make a 30 degree angle.

    How do you measure an angle with a protractor?

    1. Put the center mark of the protractor on the vertex of the angle.
    2. Turn the protractor so one ray passes through the 0 mark on the baseline.
    3. Read the number where the other ray crosses the scale that starts at 0.
    4. Write the number with the degree symbol.

    In the picture, ray A lies on the 0 mark and ray B crosses 65, so the angle measures \(65^{\circ}\).

    010203040506070809010011012013014015016017018065°AB
    The ray through B crosses the scale at 65, so the angle measures 65 degrees.

    How do you add and subtract angle measures?

    Angle measures are additive. When an angle is split into parts that do not overlap, the whole angle equals the sum of the parts. A letter such as \(x\) can stand for an unknown angle.

    ADB30°45°75°
    Ray D splits the angle into 30° and 45° parts. The whole angle is 30° + 45° = 75°.
    Worked example

    Angle PQR measures \(85^{\circ}\). Ray QS splits it into a \(35^{\circ}\) angle and an angle \(x\). Find \(x\).

    Write an equation: \(35 + x = 85\). Subtract: \(x = 85 – 35 = 50\). Check: \(35 + 50 = 85\). The unknown angle is \(50^{\circ}\).

    PSR35°x85°
    The whole angle is 85° and one part is 35°. The other part is x.

    Measuring and Adding Angles: frequently asked questions

    What is an angle measure?

    An angle measure tells how many one-degree angles fit in the turn between two rays. An angle that is 40 one-degree angles wide measures \(40^{\circ}\).

    Why does a circle have 360 degrees?

    A circle is defined as a full turn, and a full turn is cut into 360 equal one-degree angles. Half of a circle is \(180^{\circ}\) and a quarter is \(90^{\circ}\).

    Which scale of the protractor should I read?

    Read the scale that starts at 0 on the ray that lies on the baseline. If the baseline ray points right, use the scale that starts at 0 on the right. If it points left, use the other scale.

    What if neither ray is on the 0 mark?

    Read both rays on the same scale and subtract the smaller number from the larger one. Rays at \(30^{\circ}\) and \(85^{\circ}\) make an angle of \(55^{\circ}\).

    How do I find an unknown angle?

    Write an equation with a letter for the unknown part, such as \(35 + x = 85\), and then subtract the known part from the whole.

    What does a grade 4 angles lesson say about turns?

    A quarter turn is 90 degrees, and a half turn is 180 degrees. A three-quarter turn adds up to 270 degrees. For example, a clock minute hand moves 360 degrees in 60 minutes, so it covers 120 degrees in 20 minutes. Therefore every angle is a fraction of one full circle.

    How do you line up a protractor?

    Put the center hole on the vertex. Then set one ray on the 0 mark of the baseline. Next, follow the scale that starts at 0 and read where the other ray crosses it. A common mistake is reading the wrong scale, which gives 125 instead of 55. Because a narrow angle should read below 90, check that the number makes sense.

    How do you add and subtract angle measures?

    Parts that do not overlap add up to the whole. If angle AOD is 40 degrees and angle DOB is 35 degrees, then angle AOB is 75 degrees. To find a missing part, subtract. For instance, a 120 degree angle with a 52 degree part leaves \(x = 68\). In other words, write \(52 + x = 120\) and solve for the letter.

    How can you practice measuring at home?

    Cut an index card corner and a paper plate wedge, then measure both with a protractor. Next, predict each measure before you read the scale. After that, compare your guesses with the readings and adjust. Later, try the worksheet to practice drawing and adding angles.
