5th Grade Converting Units and Line Plots Worksheet with Answers

    Key takeaway: This grade 5 conversions line plots worksheet gives 22 printable problems on converting customary and metric units and on reading line plots with fractions. The first twelve problems convert one unit at a time, from feet to inches up to minutes to hours. Later problems use a table, line plots and word problems about a lemonade stand, a hiking trail and pancake milk. CCSS 5.MD.A.1 and 5.MD.B.2 skills are covered, and a separate key is included.

    These 22 problems practice converting customary and metric units and using line plots with fractions, the skills in standards 5.MD.A.1 and 5.MD.B.2. The first problems convert one step at a time. Later problems add tables, line plots, and multi-step word problems from bake sales, hikes, and the kitchen.

    Grade 5Common Core: 5.MD.A.1 · 5.MD.B.2

    Grade 5 Conversions Line Plots Worksheet: problems 1–5

    1. Feet to inches

    Convert \(3\text{ ft}\) to inches.

    FeetInches001122243?
    Each foot is 12 inches.

    2. Yards to feet

    Convert \(7\text{ yd}\) to feet.

    3. Pounds to ounces

    Convert \(5\text{ lb}\) to ounces.

    4. Gallons to quarts

    Convert \(6\text{ gal}\) to quarts.

    5. Meters to centimeters

    Convert \(4\text{ m}\) to centimeters.

    kmmcmmm×1000÷1000×100÷100×10÷10Moving right: multiply (units get smaller)Moving left: divide (units get larger)
    Use the arrow from m to cm.

    Grade 5 Conversions Line Plots Worksheet: problems 6–10

    6. Kilograms to grams

    Convert \(2.5\text{ kg}\) to grams.

    7. Inches to feet

    Convert \(60\text{ in}\) to feet.

    8. Ounces to pounds

    Convert \(48\text{ oz}\) to pounds.

    9. Cups to quarts

    Convert \(20\text{ c}\) to quarts.

    1 gallon1 qt1 qt1 qt1 qt1 pt1 pt1 pt1 pt1 pt1 pt1 pt1 ptcccccccccccccccc
    One quart is 4 cups.

    10. Millimeters to centimeters

    Convert \(450\text{ mm}\) to centimeters.

    Grade 5 Conversions Line Plots Worksheet: problems 11–15

    11. Milliliters to liters

    Convert \(3{,}500\text{ mL}\) to liters.

    12. Minutes to hours

    Convert \(150\text{ min}\) to hours. Write the answer as a decimal and as hours and minutes.

    13. Complete the table

    Complete the table. Each row shows the same length in three units.

    YardsFeetInches13362??4??
    Fill in each ? with the matching length.

    14. Compare lengths

    Maya has a 5-foot board and a 62-inch board. Convert to the same unit and tell which board is longer.

    15. Counting on a line plot

    Priya measured 11 leaves in inches. Find how many leaves are exactly \(\frac{3}{4}\) inch long and how many are shorter than \(\frac{3}{4}\) inch.

    01/41/23/41Leaf length (inches)
    Lengths of 11 leaves.

    Grade 5 Conversions Line Plots Worksheet: problems 16–20

    16. Range of rainfall

    The line plot shows the rainfall on 9 days. Find the difference between the greatest and the least amount.

    01/81/43/81/25/83/47/81Rainfall (inches)
    Daily rainfall in inches, in eighths.

    17. Two ribbons

    Aisha has two ribbons. One is 3 ft 8 in long and the other is 2 ft 7 in long. Find their total length in inches, then in feet and inches.

    3 ft 8 in2 ft 7 inTotal = ?
    Two ribbons laid end to end.

    18. Lemonade stand

    Sofia fills a 3-gallon cooler with lemonade for the bake sale and sells it by the cup. She sells 35 cups. How many cups are left?

    19. Trail mix bags

    Ethan packed 8 bags of trail mix. The line plot shows the weight of each bag in pounds. Find the total weight, then find how much each bag would weigh if all bags were filled equally.

    01/81/43/81/25/83/4Weight of a bag (pounds)
    Weights of 8 bags of trail mix.

    20. Hiking trail

    A trail is 2.5 miles long. Jamal has walked 9,240 feet. How many feet are left? How many miles is that?

    Grade 5 Conversions Line Plots Worksheet: problems 21–22

    21. Water bottles

    Priya has three bottles that hold 750 mL each. Can she pour all the water into a 2 L jug? Explain.

    22. Pancake milk

    Diego makes 6 batches of pancakes for the school breakfast. Each batch uses 3 cups of milk. Milk comes in 1-quart cartons. How many cartons must he buy, and how many cups are left over?

    Converting Units and Line Plots: Grade 5 worksheet answer key

    What are 5th grade unit conversion problems like?

    Problems 1 to 6 are warm-ups: 3 ft to inches, 7 yd to feet, 5 lb to ounces, 6 gal to quarts, 4 m to centimeters and 2.5 kg to grams. Then problems 7 to 12 flip the direction, so 60 in becomes feet and 150 min becomes hours. Problem 12 asks for the answer twice, as a decimal and as hours and minutes, which exposes the common slip of writing 2.30 for 2 hours 30 minutes.

    How do the word problems combine conversion and line plots?

    Problem 14 compares a 5-foot board with a 62-inch board, so students must convert before they compare. Problem 17 adds 3 ft 8 in and 2 ft 7 in, which needs carrying inches into feet. In problem 18, Sofia sells 35 cups from a 3-gallon cooler, so the 48 cups in the cooler matter. Problems 15, 16 and 19 return to line plots, where students count Xs, find a range and total the weights of 8 trail mix bags.

    How can you check work on this grade 5 conversions line plots worksheet?

    Estimate first. A larger unit means fewer units, so 450 mm must be less than 450 cm. Also in problem 21, three bottles of 750 mL give 2,250 mL, which is more than a 2 L jug, so the answer is no. Therefore always write units with each result.

    How should you wrap up this unit practice?

    Circle each answer where you multiplied but should have divided. Then redo those items with a small arrow from big unit to small unit. After that, compare with the key and try the ten-question quiz.

    Next step after this grade 5 conversions line plots worksheet: Converting Units and Line Plots worksheet answer key

    Printable PDF · Worksheet

    Grade 5 Converting Units and Line Plots worksheet

    • 📄 US Letter
    • 💾 71 KB
    • 🖨️ Black and white friendly
    Download the PDF

    See every chapter on the Grade 5 math page.
