Precalculus Unit Circle Test Answer Key – Grading Rubric PDF

    Key takeaway: This precalculus unit circle test answer key lists every answer for the 20-point test and the reasoning behind it. Each solution has a rubric, so graders can give partial credit for correct setups. Equivalent exact forms count as correct. The key supports standard F-TF.A.2, and it points out the sign checks that separate full marks from partial marks.

    Scoring guide and worked solutions for the radians and unit circle test. Each note shows how partial credit is split. The total is 20 points. Accept equivalent exact forms such as 1/sqrt(3) when they are simplified correctly.

    PrecalculusCommon Core: F-TF.A.1 · F-TF.A.2 · F-TF.A.3 · F-TF.A.4

    Precalculus Unit Circle Test Answer Key: questions 1–5

    1. Converting angle measures (2 points)

    1. \(225\cdot\frac{\pi}{180}=\)\(\frac{5\pi}{4}\)
    2. \(\frac{7\pi}{6}\cdot\frac{180^{\circ}}{\pi}=\)\(210^{\circ}\)

    Scoring: 1 point for each correct conversion.

    2. Coterminal and reference angles (2 points)

    1. \(\frac{23\pi}{6}-2\pi=\)\(\frac{11\pi}{6}\)
    2. The angle \(\frac{11\pi}{6}\) is in Quadrant IV, and \(2\pi-\frac{11\pi}{6}=\)\(\frac{\pi}{6}\)

    Scoring: 1 point for each part; award 0.5 for a correct method with an arithmetic slip.

    3. Point on the unit circle (3 points)

    1. \(P=(\cos\frac{7\pi}{6},\sin\frac{7\pi}{6})=\)\((-\frac{\sqrt{3}}{2},-\frac{1}{2})\)
    2. \(\tan\frac{7\pi}{6}=\frac{-1/2}{-\sqrt{3}/2}=\frac{1}{\sqrt{3}}=\)\(\frac{\sqrt{3}}{3}\)
    3. \(\sin(-\frac{7\pi}{6})=-\sin\frac{7\pi}{6}=-(-\frac{1}{2})=\)\(\frac{1}{2}\)
    θ = 7π/6P (-√3/2, -1/2)P’ (-√3/2, 1/2)
    The point for -7pi/6 is the reflection of P across the x-axis.

    Scoring: 1 point per part: for (a) 0.5 for each correct coordinate; for (b) 0.5 for the quotient setup and 0.5 for rationalizing; for (c) 0.5 for using the odd property and 0.5 for the value.

    4. Arc length of a sector (2 points)

    1. \(150^{\circ}=\)\(\frac{5\pi}{6}\)
    2. \(s=15\cdot\frac{5\pi}{6}=12.5\pi\approx\) 39.27 in
    r = 15 inθ = 150°s = 12.5π in
    The crust is 12.5pi inches long.

    Scoring: 1 point for each part.

    5. Angular and linear speed (3 points)

    1. \(\omega=\frac{2\pi}{8}=\)\(\frac{\pi}{4}\text{ rad/min}\)
    2. \(v=r\omega=50\cdot\frac{\pi}{4}=12.5\pi\approx\) 39.27 ft/min
    3. \(12.5\pi\cdot 20=250\pi\approx\) 785.40 ft

    Scoring: 1 point for each part.

    Precalculus Unit Circle Test Answer Key: questions 6–9

    6. Solving trigonometric equations (2 points)

    1. The reference angle is \(\frac{\pi}{6}\). The value is negative, so the terminal side is in Quadrant II or III: \(\theta=\pi-\frac{\pi}{6}=\)\(\frac{5\pi}{6}\) and \(\theta=\pi+\frac{\pi}{6}=\)\(\frac{7\pi}{6}\).
    2. The reference angle is \(\frac{\pi}{4}\). The value is positive, so the terminal side is in Quadrant I or III: \(\theta=\)\(\frac{\pi}{4}\) and \(\theta=\pi+\frac{\pi}{4}=\)\(\frac{5\pi}{4}\).

    Scoring: 1 point for each part (0.5 for each correct angle).

    7. Even and odd (2 points)

    1. \(\tan(-\frac{5\pi}{4})=-\tan\frac{5\pi}{4}=-1\), so -1
    2. \(f(-x)=(-x)^{2}\sin(-x)=-x^{2}\sin x=-f(x)\), so f is odd

    Scoring: 1 point for each part; part (b) needs the computation of f(-x).

    8. Periodicity of sine (2 points)

    1. The graph repeats every \(2\pi\).
    2. \(\sin\frac{13\pi}{6}=\sin(\frac{\pi}{6}+2\pi)=\sin\frac{\pi}{6}=\)\(\frac{1}{2}\). Also \(-\frac{7\pi}{6}+2\pi=\frac{5\pi}{6}\) and \(\sin\frac{5\pi}{6}=\)\(\frac{1}{2}\)
    -11xy-2π-3π/2-π-π/2π/2π3π/22π
    Sine repeats its values every 2pi: for example sin(5pi/6) = sin(-7pi/6) = 1/2.

    Scoring: 1 point for the period; 1 point for both values (0.5 each).

    9. Unit circle coordinates (2 points)

    1. \(\sin^{2}\theta=1-\frac{64}{289}=\frac{225}{289}\); sine is positive in Quadrant II, so \(\sin\theta=\frac{15}{17}\)
    2. \(\tan\theta=\frac{15/17}{-8/17}=\)\(-\frac{15}{8}\)

    Scoring: 1 point for each part; part (b) can be earned with an incorrect part (a) if the quotient is correct.

    Scoring summary

    Total

    20 points: add the points of every question of this precalculus unit circle test answer key.

    What are the key results for questions 1 to 3?

    Question 1 gives \(\frac{5\pi}{4}\) and \(210^{\circ}\). Question 2 gives \(\frac{11\pi}{6}\) and a reference angle of \(\frac{\pi}{6}\). For question 3, the point is \((-\frac{\sqrt{3}}{2},-\frac{1}{2})\), so tangent is \(\frac{\sqrt{3}}{3}\).

    How do you grade the speed question?

    The angular speed is \(\frac{\pi}{4}\) radians per minute, worth one point. The linear speed is \(\frac{25\pi}{2}\) ft per minute, worth another. A third point rewards correct units. Accept 39.27 ft per minute when the question allows decimals.

    What does the precalculus unit circle test key say about questions 6 to 9?

    Question 6 needs \(\frac{5\pi}{6}\) and \(\frac{7\pi}{6}\) for cosine. Question 7 gives \(\tan(-\frac{5\pi}{4})=-1\), and \(x^2\sin x\) is odd. In question 9, \(\sin\theta=\frac{15}{17}\) because the angle is in Quadrant II.

    Which partial-credit rules apply?

    If a student lists only one solution in question 6, award one of two points. However, give no point for an answer outside \([0,2\pi)\).

    How can the rubric guide reteaching?

    Count which rubric line was missed most, then reteach that exact skill. For instance, sign errors respond well to a quadrant chart. After that, assign a short retest with fresh angles and compare the results with the first attempt.
