Grade 6 Volume of Rectangular Prisms Lesson: 6th Grade Fractions

    Key takeaway: This grade 6 volume prisms lesson explains how to count the unit cubes that fill a rectangular box. Multiply length, width, and height, or multiply the base area by the height, and write the answer in cubic units. The lesson also shows what happens when an edge is a fraction, which is the main new idea in standard 6.G.A.2.

    First, you picture a layer of cubes on the floor of a box. Next, you stack the layers. Finally, you switch to fractions and see why a cube with edge one half holds one eighth of a cubic unit.

    The volume of a rectangular prism is the number of unit cubes that fill it. Multiply length, width, and height, or multiply the base area by the height. Edges can be fractions: a prism packed with cubes of edge one half holds eight cubes in each cubic unit. Volume is written in cubic units.

    Grade 6Common Core: 6.G.A.2

    Grade 6 Volume Prisms Lesson: key facts

    • \(V = \ell \times w \times h\) and \(V = B \times h\) give the same volume.
    • Volume is measured in cubic units such as in\(^3\) or ft\(^3\).
    • A cube with edge \(\frac{1}{2}\) has volume \(\frac{1}{8}\) cubic unit.
    • To find a missing height, divide the volume by the base area.

    What is the volume of a rectangular prism?

    Volume is the amount of space inside a solid. It is measured in cubic units. A unit cube has edges of 1 unit and a volume of 1 cubic unit. If a rectangular prism is packed with unit cubes and nothing is left over, the number of cubes is the volume.

    5 units2 units3 units5 x 3 x 2 = 30 unit cubes
    Figure 1. Counting unit cubes layer by layer: 15 cubes in each of 2 layers.

    How do you find volume when the edges are fractions?

    Use smaller cubes. A cube with edges of \(\frac{1}{2}\) inch has a volume of \(\frac{1}{8}\text{ in}^3\), because 8 of them fill a 1-inch cube. A prism that is \(2\text{ in}\) by \(1\frac{1}{2}\text{ in}\) by \(1\text{ in}\) holds \(4 \times 3 \times 2 = 24\) of these cubes, so its volume is \(24 \times \frac{1}{8} = 3\text{ in}^3\). Multiplying the edges gives the same answer: \(2 \times \frac{3}{2} \times 1 = 3\).

    2 in1 in1 1/2 in24 cubes, each 1/8 cubic inch
    Figure 2. Packing with half-inch cubes: 24 cubes of \(\frac{1}{8}\text{ in}^3\) each.
    Volume formulas
    Formula Meaning
    \(V = \ell \times w \times h\) length times width times height
    \(V = B \times h\) area of the base times height

    The two formulas agree because the base area is \(B = \ell \times w\). Think of the prism as layers: each layer holds \(B\) cubes, and there are \(h\) layers.

    4 units3 units3 unitsB = 12, h = 3, V = 12 x 3 = 36
    Figure 3. The shaded base holds 12 cubes, and there are 3 layers.

    How do you find the volume step by step?

    1. Write the three edge lengths in the same unit.
    2. Write \(V = \ell \times w \times h\).
    3. Substitute the lengths. Change mixed numbers to fractions.
    4. Multiply, then write the answer in cubic units.

    Example. A box is \(2\frac{1}{2}\text{ ft}\) long, \(1\frac{1}{2}\text{ ft}\) wide, and \(2\text{ ft}\) tall.

    \(V = \frac{5}{2} \times \frac{3}{2} \times 2 = \frac{15}{4} \times 2 = \frac{15}{2} = 7\frac{1}{2}\text{ ft}^3\)

    2 1/2 ft2 ft1 1/2 ft
    Figure 4. The box in the example: \(V = 7\frac{1}{2}\text{ ft}^3\).

    If a measurement is missing, divide: \(h = V : B\). A prism with \(V = 60\text{ ft}^3\) and \(B = 15\text{ ft}^2\) has \(h = 60 : 15 = 4\text{ ft}\).

    Volume of Rectangular Prisms: frequently asked questions

    What is the formula for the volume of a rectangular prism?

    Volume equals length times width times height, \(V = \ell wh\). It can also be written \(V = Bh\), where \(B\) is the area of the base.

    Why is volume measured in cubic units?

    Volume counts how many unit cubes fill a solid. A prism that holds 30 cubes with 1-inch edges has a volume of 30 cubic inches.

    How do you find volume with fractional edge lengths?

    Either multiply the fractions, or pack the prism with cubes whose edge is the unit fraction. A cube with edge \(\frac{1}{3}\) has volume \(\frac{1}{27}\) cubic unit.

    How is volume different from surface area?

    Volume measures the space inside a solid in cubic units. Surface area measures the total area of the outside faces in square units.

    How do you find a missing edge of a prism?

    Divide the volume by the area of the base. For a volume of 60 cubic feet and a base area of 15 square feet, the height is \(60 : 15 = 4\) feet.

    What is the volume of a rectangular prism?

    Volume measures the space inside a solid, so it counts cubes rather than squares. Picture a crate with a floor of 6 feet by 4 feet and a height of 3 feet. Its bottom layer holds 24 cubes. Three layers give 72 cubic feet. The formula \(V = \ell \times w \times h\) is just that stacking story in short form.

    How do you find volume when the edges are fractions?

    Imagine filling a box with small cubes of edge one half. Eight of those cubes fit in one full cubic unit, because two fit along each edge. Therefore each small cube has volume \(\frac{1}{8}\). A box that is 4 inches long, one half inch wide, and 3 inches tall holds 6 cubic inches.

    How does a grade 6 volume prisms lesson handle a missing height?

    Work backward with division. A prism has a volume of 252 cubic feet and a base area of 36 square feet. Divide 252 by 36, and the height is 7 feet. In other words, the base area and the height are two factors of the volume.

    What mistakes should you avoid?

    Some students add the three edges instead of multiplying. Others write square units for a volume. Also, a cube such as a 6-inch gift box needs the edge used three times , which gives 216, not 36.

    Because volume uses three dimensions, doubling every edge multiplies the volume by eight. A 2 by 2 by 2 cube holds 8 cubic units, while a 4 by 4 by 4 cube holds 64. This surprises many students, so test it with blocks.

    Practice volume after this lesson

    Fill a shoebox with sugar cubes or blocks, count one layer, and predict the full count before you stack. Then try the worksheet and begin with the whole-number boxes. Once those feel easy, move on to the fractional edges and the stage built from two prisms.

    Next step after this grade 6 volume prisms lesson: Volume of Rectangular Prisms worksheet
